ECLISSE Classic Fire-Rated Pocket Door Kit – Single

From £682.80 incl. VAT

    Note: Self Close Mechanism - Max door panel weight is 40Kg.
Add to Wishlist
Add to Wishlist

The independently fire-tested and certified ECLISSE Pocket Door System – Fire-Rated Single (FD 30) when bought with a self closing mechanism

This sliding pocket door system includes all the benefits of the standard ECLISSE Classic Pocket Door System plus a specially designed jamb/architrave kit made from a high-density slow burning hardwood.

  • Certified for use with the following Jeldwen 44mm FD30 door panels (not supplied) under field of application report PAR /10057/01 Revision D
    • Moulded: Arlington 6 panel, Atherton 4 Panel, Bostonian 6 Panel, Oakfield 4 Panel, Oregon 4 panel, Linea Panel
    • Flush: Paint Grade Premium, Ash panel, Beech Panel, Koto Panel,Walnut Panel,White Oak Panel
    • Jeldwen doors are available from Midland Building Products, Travis Perkins, B&Q, Magnet and Howdens.
  • Compatible and certified for use with the BIAS Soft-Close Anti-Slam

  • Now includes a choice of white or brown intumescent seals

  • Approve for use with our Essentials round and square flush pull handles


Refer to the report below for information on which non-essential hardware (i.e. push plates, kick plates, handles) has been approved for use.

If you would like any further information regarding the FD30 pocket door systems, please contact the customer service team on 07957 855440.

Download Field of Application Report PAR /10057/01 Revision E



There are three main advantages of using this special wood rather than a cheaper right angled plasterboard profile used in other fire-rated pocket door systems:

  • The projecting corners at the pocket entrance and door post are in wood and not plasterboard and so not easily chipped; they keep their looks over time.
  • They allow for a wider passage size for the size of the door as the door does not need to protrude into the pocket as much as it would with a plasterboard system.
  • The finished wall thickness is still a standard 100 mm, using 12.5 mm standard fire board.


  • Not sure which size you need? Have a look at this SIZE CHART & TECHNICAL SPEC. Still have questions? Call our friendly Customer Services Team on 07957 855440.
  • Need a non standard size? Call for a quote.


  • Order online before 11am on a weekday for a next working day delivery to UK mainland. For delivery to islands, Highlands, N Ireland and ROI please contact us.
  • FREE delivery to UK mainland for this frame and jamb when ordered online.   For delivery to islands, Highlands, N Ireland and ROI please contact us.
  • FREE delivery to UK mainland for accessories and door furniture when ordered at the same time as this product.


SKU: 0abe10921786-1-1 Categories: , , , ,
It’s recommended not to book a joiner or tradesperson until after your kit has arrived.


  • Complete with special jamb/architrave kit made from a very special hard wood called Pterygota bequertii commonly known as Koto, pre-treated with intumescent primer.
  • **For use with 44mm FD30 rated fire doors (not included)**
  • Maintenance-free track and runners.
  • Fully adjustable front and rear doorstop.
  • Runners are tested to 100,000 cycles (that’s around 25 years of average use!)
  • Anti-warp door profile
  • Self-centering floor guide
  • 15 year guarantee on the complete ECLISSE steel pocket system and runners
  • Fully tested and approved by International Fire Consultants PAR/10057/01 Revision B

Additional information

Panel Size in mm or (feet/inch)

926X2040, 914X1981 (3' 0" X 6' 6"), 726X1981 (2' 6" X 6' 6"), 626X2040, 610×1981 (2' 0" X 6' 6"), 686X1981 (2' 3" X 6' 6"), 838X1981 (2' 9" X 6' 6"), 1026X2040, 726X2040, 826X2040, 711X1981, 813X2032, 864X2032
